The SCH16F is a micro encoder with a quill shaft open on one side. It is used for... more
Product information "Incremental Encoder SCH16F"
The SCH16F is a micro encoder with a quill shaft open on one side. It is used for automatic machines in the field of packaging and medicine technology, in pick-and-place machines and during technical inspections.
Characteristics:
- Micro rotary encoder with quill shaft open on one side
- Rotary encoder: Ø 16mm
- Quill shaft inside: Ø 1.5mm - Ø 1/8 inch
- Resolution up to 5 000 ppr
- IP50
Related links to "Incremental Encoder SCH16F"
Technische Daten anfordern ...Technische Daten anfordern ...
Technical data "Incremental Encoder SCH16F"
Electrical Specifications
| Code | Incremental |
| Resolution | 1 to 5.000 ppr (pulses per revolution) |
| Supply Voltage | 4.5 Vdc min. to 30 Vdc max. ** |
| Current Consumption | 1 to 3.600 - 35 mA max. (no load) > 3.600 - 45 mA max. (no load) |
| Output Voltage | Low: 500 mV max. at 10 mA High (Vin - 0.6) at -10 mA (Vin - 1.3) at -25 mA |
| Output Current | 20 mA max. load per output channel ** |
| Frequency Response | 200 kHz max. ** |
| Output Format | Two channel (A,B) quadrature with Index (Z) and optional complementary (A-, B-, Z-) outputs |
| Phase Sense | A leads B clockwise (CW) from the mounting end of the encoder |
| Index | Gated with Channels A and B high |
| Accuracy | +/- 26 arc-min |
| Output | ASIC Differential |
| Electrical Protection | Reverse polarity protected Output short circuit protected |
| Noise Immunity | Tested to EN61000-6-2 : 2005 (industrial environments) and EN 61000-6-3 : 2007 (residential, commercial, and light-industrial environments) for Electromagnetic compatibility (EMC) |
Mechanical Specifications
| Material | Housing: Aluminium / Brass Cap: Aluminium Hollow Shaft: Brass |
| Weight | Encoder: ~ 15 gr (0.53 oz) Cable: 50 gr / meter (1.76 oz / meter) |
| Bearing Life | > 1.9 x 1010 revolutions at rated load |
| Bearing Pre-Load | 1 - 3.600 rpm 2 (N) 4.000 - 5.000 ppr 7 (N) |
| Shaft Speed | 12.000 rpm (max.) |
| Starting Torque | < 0.005 Nm (0.708 oz-in) at 25°C |
| Mass Moment of Inertia | 0,25 gcm2 (3.54 x 10-6 oz-in-sec2) |
| Hollow Shaft Loads | Axial: 10 N (2.25 lbs) max. Radial: 10 N (2.5 lbs) max. |
Environmental Specifications
| Operating Temperature | -20° to +70°C |
| Storage Temperature | -20° to +85°C |
| Shock | 100 G / 11 ms |
| Vibration | (10-2.000 Hz) /10 G |
| Bump | 10 G / 16 ms (1.000 x 3 axis) |
| Humidity | 98% RH without condensation |
| Enclosure Rating | IP50 / Nema 5 (approx.) - flat cable |
Connection Options
| Cable | 8 leads (0.05 mm2, 30 AWG) twisted pairs, shielded |
| Flat Cable | 10 lead flat cable with IDC connector |
** = It is recommended user, not to combine max. values for all 3 paramteres
